MiMo-V2.5 Omni · NVFP4 KV · TP=2 · 2× DGX Spark

Mia's MiMo-V2.5 Dual DGX Spark Start Script — serve MiMo-V2.5 Omni (MiMoV2OmniForCausalLM + MTP1) with 4-bit NVFP4 KV tensor-parallel across two NVIDIA DGX Spark (GB10) boxes with Ray, on port 8888.

Repo: MiaAI-Lab/MiMo-V2.5-vLLM-Dual-DGX-Sparks

This tree is Omni only — no DFlash lane.

KV cache · 1M context · 3 concurrent

max_num_seqs=3 and max_model_len=1M do not reserve 3×1M in VRAM. The engine shares one KV token pool across live requests.

Measured at boot on this 2× Spark pair (Omni MTP1 @ GMU 0.83, max_model_len=1_000_000, max_num_seqs=3):

3 × 1,000,000 = 3,000,000 tokens needed for three full-1M streams
pool          = 2,704,932 tokens available
→ only ~2 full-1M streams fit; a 3rd deep 1M waits (queues) until KV frees

Practical reading:

• 2 agents at full 1M — fits.
• 3 agents at full 1M — third scheduled but blocked/queued on KV.
• 3 agents at moderate depth — all run if total KV ≤ ~2.70M.

Confirm live numbers in vllm.log after launch:

Available KV cache memory: …
GPU KV cache size: 2,704,932 tokens
Maximum concurrency for 1,000,000 tokens per request: 2.70x

Performance (this pair · 2026-07-14)

Token speed bench (tok.sh) against http://localhost:8888/v1/chat/completions after Omni MTP1 bring-up.

Comparison

Per-run mean Gen / E2E tok/s (what the tool prints), plus cumulative tok/s = total tokens ÷ wall clock for that concurrency level:

Best single-stream: 30.00 gen tok/s / 31.09 E2E. Peak shared throughput on this shape: ~56 tok/s cumulative @ C3. Tony’s published Omni MTP1 reference (GMU 0.84 / seqs=8) is ~31.9–32.1 single-stream.

Hardware

• Docker + NVIDIA Container Toolkit on both nodes
• Passwordless SSH from head → worker
• Weights readable on both nodes (local HF hub preferred)

Quick start

From the head node:

cd /mnt/models/MiMo

# Optional overrides
# export HEAD_IP=10.0.0.1 WORKER_IP=10.0.0.2 SSH_USER=zurih
# export MAX_MODEL_LEN=1000000 MAX_NUM_SEQS=3 GPU_MEMORY_UTILIZATION=0.83

bash start.sh          # download/sync weights if needed → containers → Ray → Omni → chat verify
bash stop.sh           # stop vLLM + Ray + containers (containers left stopped, not removed)

Useful modes:

bash start.sh --check      # print plan + weight completeness (no download / no launch)
bash start.sh --teardown   # force tear down cluster
bash stop.sh --check       # dry-run stop

Exit 0 from start.sh only after a real /v1/chat/completions returns non-empty content.
Always bash start.sh — never source start.sh (sourcing runs main).

Smoke

curl http://127.0.0.1:8888/v1/models | jq .

curl http://127.0.0.1:8888/v1/chat/completions \
  -H 'Content-Type: application/json' \
  -d '{
    "model": "MiMo-V2.5-NVFP4",
    "messages": [{"role":"user","content":"Reply with just: ok"}],
    "max_tokens": 16,
    "temperature": 0,
    "chat_template_kwargs": {"enable_thinking": false}
  }'

Agent clients (OMP / OpenAI-compatible)

Served model id: MiMo-V2.5-NVFP4 (MiMoV2OmniForCausalLM).
Point agents at http://<head>:8888/v1 (or http://localhost:8888/v1 on the head).

Omni multimodal (required in client config)

This is a full Omni endpoint — not text-only. Advertise all four input modalities:

input: [text, image, video, audio]

Server per-prompt caps (launch-omni.sh):

(--limit-mm-per-prompt '{"image":4,"video":1,"audio":1}' · --mm-encoder-tp-mode data)

If OMP/UI only lists text+image, the model entry is wrong — keep video and audio in input:.

Recommended request params

Concurrency: deep 1M agents ≤ 2 at once (KV pool ≈ 2.5×); a 3rd full-1M queues. Multimodal tokens also consume the shared KV pool.

OMP (~/.omp/agent/)

Default role (config.yml):

modelRoles:
  default: vllm-spark1/MiMo-V2.5-NVFP4   # or mimo-local/MiMo-V2.5-NVFP4

Provider + model (merge into models.yml — full Omni):

providers:
  vllm-spark1:
    baseUrl: http://spark1-cx7:8888/v1   # or http://10.0.0.1:8888/v1
    apiKey: dummy
    api: openai-completions
    auth: none
    models:
      - id: MiMo-V2.5-NVFP4
        name: MiMo-V2.5 Omni (text+image+video+audio · TP2 / 1M / MTP1)
        reasoning: false
        input: [text, image, video, audio]
        contextWindow: 1000000
        maxTokens: 32768
        # Server mm: image≤4 video≤1 audio≤1
        # pi-only: params {temperature: 0, top_p: 0.95, repetition_penalty: 1.08, chat_template_kwargs {enable_thinking: false}}

  mimo-local:
    baseUrl: http://localhost:8888/v1
    apiKey: local
    api: openai-completions
    auth: none
    models:
      - id: MiMo-V2.5-NVFP4
        name: MiMo-V2.5 Omni Local (text+image+video+audio)
        reasoning: false
        input: [text, image, video, audio]
        contextWindow: 1000000
        maxTokens: 32768
        # Server mm: image≤4 video≤1 audio≤1
        # pi-only: params {temperature: 0, top_p: 0.95, repetition_penalty: 1.08, chat_template_kwargs {enable_thinking: false}}

Copy-paste file: examples/omp-models.snippet.yml.

Generic OpenAI clients

export OPENAI_BASE_URL=http://10.0.0.1:8888/v1
export OPENAI_API_KEY=dummy
# model = MiMo-V2.5-NVFP4
# multimodal: send image_url / audio / video parts per OpenAI-compatible content arrays

What start.sh does

1. Precheck — GPU + SSH to worker
2. Weights — if missing/incomplete on the head, hf download (resumable); then rsync Omni target to the worker’s ~/.cache/huggingface/hub
3. Containers — mimo-nvfp4 on both nodes (overlay image + model + recipe binds)
4. Mods + patches — recipe/apply-mods.sh when recipe/mods/ is present; then engine patches/*.py on both ranks
5. Ray — head then worker, 1 GiB object store cap, wait for 2.0/2.0 GPU
6. vLLM — recipe/env.sh + Omni overrides → launch-omni.sh on port 8888
7. Verify — poll /v1/models, then chat; relay/fix loop on failure

Default serving shape

All overridable via environment before bash start.sh.

Weights

Point at another cache with MODEL_HOST_DIR / TARGET_REPO / TARGET_REVISION. --check never downloads.

Runtime stack (required)

This is not stock pip vLLM.

• Runtime image (GHCR): ghcr.io/miaai-lab/mimo-v2.5-vllm-dual-dgx-sparks:20260704 (also :latest)
  • Base lineage: Tony’s Spark DEV vLLM 0.21.1rc1.dev85 (CUDA 13.2 / GB10)
  • Pull: docker pull ghcr.io/miaai-lab/mimo-v2.5-vllm-dual-dgx-sparks:20260704
  • start.sh skips GHCR if that tag is already local; if the worker lacks it but the head has it, it streams head → worker (docker save|load) instead of pulling. Optional: SKIP_IMAGE_PULL=1, or LOCAL_IMAGE_ALIASES=my-local:tag to retag.
• vLLM: 0.21.1rc1.dev85+gd87ee1893 (CUDA 13.2 / GB10)
• Ray required for cross-node TP=2

Mods (recipe/mods/)

Engine patches (patches/)

Applied at bring-up (idempotent). Especially useful for the NVFP4-KV lane:

• patch_diffkv_noncausal.py
• patch_draft_cache_auto.py
• patch_spec_dtype_guard.py

Repository layout

.
├── README.md
├── start.sh                 # full two-node Omni bring-up + verify
├── stop.sh                  # stop serve + containers
├── .gitignore
├── assets/
│   └── mimo.jpg             # README hero
├── examples/
│   └── omp-models.snippet.yml  # OMP / agent client snippet
├── recipe/
│   ├── env.sh               # in-container env (sourced at launch)
│   ├── apply-mods.sh
│   ├── launch-omni.sh       # MiMoV2OmniForCausalLM + MTP1 + mm limits
│   └── mods/                # seven runtime mods
└── patches/
    ├── Dockerfile           # overlay image
    └── patch_*.py           # engine patches

Networking (this cluster)

export NCCL_IB_DISABLE=0
export NCCL_SOCKET_IFNAME=enp1s0f1np1
export GLOO_SOCKET_IFNAME=enp1s0f1np1
export NCCL_IB_HCA=rocep1s0f1
export NCCL_IB_GID_INDEX=3
export NCCL_PROTO=LL
export NCCL_MAX_NCHANNELS=2
export NCCL_NET_GDR_LEVEL=LOC

Ray object store is capped at 1 GiB per node; RAY_TMPDIR defaults to /dev/shm/ray.

Throughput tips

1. enable_thinking: false (launcher default chat-template kwargs).
2. Prefer repetition_penalty=1.0 when chasing raw tok/s; server default sampling may use 1.08 for stability.
3. Keep NCCL LL + 2 channels on the Spark interconnect.
4. First token after load is slow — expected. This recipe uses --enforce-eager (no CUDA graphs) for 1M + NVFP4-KV + MTP stability, plus cold Triton/FlashInfer warmup and a full prompt prefill over TP=2/RoCE before any output token. Later requests on a warm engine are much snappier; MTP helps decode tok/s more than TTFT.

Validated Omni MTP1 on this pair (2026-07-14, tok.sh): 30.00 gen / 31.09 E2E @ C1; cumulative ~41.7 tok/s @ C2 / ~56.1 tok/s @ C3 (tokens ÷ wall). Tony’s published reference is ~31.9–32.1 single-stream — see Performance.

Troubleshooting

Logs: host vllm.log (gitignored) mirrors /workspace/vllm.log inside the head container.

Credits

This recipe is built on tonyd2wild/MiMo-V2.5-TP2-1M-NVFP4-KV-2xDGX-Spark — Tony’s Omni MTP1 + NVFP4-KV dual-DGX Spark work (vLLM mods, DiffKV path, launch shape, and published reference numbers). Mia’s tree wraps that stack in a one-script dual-node bring-up for this cluster; performance figures above are measured here and may differ from Tony’s GMU 0.84 / max_num_seqs=8 checkpoint.

License

Recipe scripts and local patches follow upstream licenses (vLLM Apache-2.0 for DiffKV forks, as applicable). Model weights are subject to their Hugging Face licenses.
